12V 4.5Ah sealed lead acid battery
TLA1250--3220
12V 5.0Ah sealed lead acid SLA battery supply by UNICELL in Singapore
UNICELL a Leading Supplier for sealed lead acid battery In Singapore Malaysia Indonesia Philippines and Thailand since 1986 , we carry more the 66,000 model
Order code : TLA1250 (5.0Ah replace the 4.5Ah old series )
Categories: 12V 5.0Ah Sealed Lead Acid (SLA) maintenance free battery,
Description: 12V rechargeable battery
Size: Length 90 x Width 70 x Height 107 mm (with terminal) + 2mm
Weight: 0.99Kg
Terminal: F1 (4.70mm or 0.187inch)
Application: UPS, Exit light , back-up system
Specifications
Cells Per Unit: 6
Voltage Per Unit: 12 V
Capacity: 5Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F)
Weight (kg): Approx. 1.6kg
Maximum Discharge current (A): 50A (5sec.)
Internal Resistance Approx.: Approx. 35mΩ
Operating Temperature Range:
- Discharge：-15℃~50℃(5°F~122°F)
- Charge：-15℃~40℃(5°F~104°F)
- Storage：-15℃~40℃(5°F~104°F)
Nominal Operating Temperature Range: 25°C ± 3°C (77°F ± 5°F)
Float charging voltage: 13.5 to 13.8 VDC/unit Average at 25°C (77°F)
Recommended Maximum Charging current limit: 1.5A
Equalization and Cycle Service: 14.4 to 15.0 VDC/unit Average at 25°C (77°F)
Self Discharge: Unicell batteries can be stored for more than 6 months at 25°C (77°F)
Please charge batteries before using. For higher temperatures the time interval will be shorter.
Container Material: ABS(UL94-HB/File E50263)*Flammability resistance of(UL94-V0/File E88637) can be available upon request.
Fit or replace battery part no. (Cross refer or compatible chart )
Allen Bradley 1609-5350es battery (2X)
APC RBC45 battery
BB BP4-12 battery
B.B. BP4.5-12 battery
B&B BP5-12 battery
CSB GP1245 battery
CSB GP1250 battery
CSB HR5.5-12 battery
CSB HR1221WF2 battery
CT Leader CT5-12H battery (X2 for VDR F1-S1 KM PN#370472)
Douglas Guardian DG12-5 battery
EAGLE PICHER CFM12V4.6M battery
Firstpower FP1245 battery
Firstpower FP1250 battery
Genesis NP4.5-12 battery
GS PORTALAC PE4-12R battery
GS PORTALAC PE4.5-12R battery
GS PORTALAC PE12V4.5F1 battery
GS PORTALAC PE12V4.0 battery
GS PORTALAC PXL12050 battery
Global Yuasa ES4-12 battery
Hitachi HP4-12 battery
Hitachi HP412 battery
Johnson Controls JC1240 battery
Johnson Controls JC1245 battery
Long WP4-12 battery
Long WP4.5-12 battery
Long WP5-12 battery
Mei Hua MH1250 battery
MK ES4.5-12 battery
MSB MS 12-4.5 battery
Newark NP4.5-12 Battery
Neuton Power NP125 (12V5.0AH) battery
Panasonic LC-R125P battery
Panasonic LC-RB124P battery
Panasonic LC-R125P battery
Panasonic LCR-12V4BP battery
Panasonic LCR-12V5P battery
Power Battery PM124.5 Battery
Power Sonic PS-1242 battery
Power Sonic PS-1250 battery
Power Sonic PS1250 battery
Power Sonic PS-1252 battery
Powerstream BP2.2-12 battery
Unibeam HR1224W battery
Universal (UPG) UB1245 battery
Universal (UPG) UB1250 battery
Unipower WP4.5-12battery
Unicell TLA1245 battery (12V 4.5Ah)
Union Battery MX12050 Battery
Union Battery PW1204.5 Battery
Universal Battery UB1245 Battery
Universal Battery UB1250 Battery
Universal Battery UB1250A Battery
Yuasa NP2.212 Battery
Yuasa NPH2312 Battery
Yusas NP4-12 battery
Yusas NP4-12P battery
Yusas NPH5-12 battery
Yusas NPX-25 battery
Access SLA1045 battery
Access SLA1250 battery
Access SLA1240 battery
Amstron 12V 5.5Ah battery
Amstron 12V 4Ah battery
Amstron AP-1250F1 battery
Amstron 12V 4.5Ah battery
Amstron 12V 5Ah battery
Amstron 12V 5Ah battery
BB BP4-12 battery
Belkin F6H550-USB battery
Bennett X-Ray Contour Mammography battery
Best Technologies Fortress LI460VA B battery
Black & Decker CST2000 Cordless Trimmer battery
Black and Decker Sweeper - CS100 battery
Black and Decker Grasshog - CST2000 battery
Black and Decker 243215 battery
Black and Decker 243213-00 battery
Bladez Ion 150 battery
Casil 804302 battery
Casil CA1240 battery
Casil CA1245 battery
CSB GP1250 battery
CSB GP1240 battery
CSB EVX1245 battery
CSB GP412 battery
CSB 12V 4.5Ah battery
CSB GH1240 battery
CSB GH1250 battery
CSB GP1245 battery
CyberPower Systems CPS375SL battery
Datasafe NPX-25T battery
Cyclon 12V 5Ah battery
Deltech PRM1500A battery
E-Scooter E Scooter 24V 100W battery
Eagle Picher CF12V4 battery
Elk ELK-1240 battery
EnerSys 12V 4.5Ah battery
EnerSys NP4-12FR battery
Ebersys NPX-25T battery
EnerSys 12V 5Ah battery
EnerSys NP5-12 battery
EnerSys NP4-12 battery
EnerSys 12V 4Ah battery
Exide PowerWare 1000K battery
Fenton Technologies PowerPal L660 battery
Fenton Technologies PowerPal L280 battery
Fire Lite M12 battery
Freedom 803 battery
Freedom 804 battery
Genesis NP5-12 battery
Genesis NP4-12FR battery
GS Storage PE12V5 battery
GS Storage PE12V4.5F1 battery
Haze HZS12-5 battery
Hitachi HP4-12 battery
IBT BT4.5-12 battery
IBT BT5-12 battery
IBT BT4-12 battery
Interstate 12V 5Ah battery
Interstate BSL1055 battery
Interstate PC1240 battery
Interstate SLA1311 battery
Interstate 12V 4Ah battery
iZip I135 battery
iZip I130 battery
iZip I150 battery
Kung Long WP4.5-12 battery
Kung Long WP5-12 battery
Kung Long WP4-12 battery
Leadman LU550 battery
Leoch LP12-6.0 battery
Locknetics SBP1255 battery
MK ES5-12 battery
MK ES4-12 battery
Mongoose M-150 battery
Mongoose M-130 battery
Neata NT12-4.5 battery
Panasonic LC-RB124P battery
Panasonic LC-R12V4BP1 battery
Panasonic LC-R12V4BP battery
Panasonic 12V 4Ah battery
Panasonic 12V 5Ah battery
Para Systems Minuteman MBK300 battery
Para Systems Minuteman Pro 200 battery
Portalac PE12V5 battery
Power Patrol SLA1050 battery
Power Patrol SLA1055 battery
Power-Sonic 12V 5Ah battery
Power-Sonic PS-1250-F1 battery
Power-Sonic PS-1250 battery
Power-Sonic 12V 4Ah battery
Razor E125 battery
Rhino SLA 4-12 battery
Rhino SLA 5-12 battery
Ritar RT1250B battery
Ritar 12V 4Ah battery
Ritar RT1245 battery
Ritar 12V 5Ah battery
Ritar 12V 4.5Ah battery
Ritar RT1250BH battery
Ritar RT1250 battery
Ritar 12V 5.5Ah battery
Ritar RT1255 battery
Silent Knight S122 battery
Silent Knight 680 battery
Silent Knight S121 battery
Silent Knight N5HR battery
Silent Knight N7HR battery
Silent Knight 712 battery
Silent Knight Enerjet battery
SL Weber PowerHouse 550 battery
SL Weber PowerHouse 500 battery
SL Weber PowerHouse 320T battery
SL Weber PowerHouse 250 battery
SL Weber PowerHouse 280T battery
Tempest TR4-12 battery
Tempest TR5-12 battery
Tripp Lite 450VA battery
Tripp Lite BC Personal 200 battery
Union MX-12050 battery
Union MX-12040 battery
Unison DP600 battery
Universal UB1250 battery
Universal D5741 battery
Upsonic PC Mate 25 battery
Vision CP1250 battery
Vision CP1250H battery
Yuasa NP5-12 battery
Yuasa NP4-12FR battery
Yuasa NP4-12 battery
Yuasa 12V 5Ah battery
Yuasa 12V 4Ah battery
Fit or replace product model: (Cross refer or compatible chart )
ADT security alarm 804302 home alarm battery
Black and Decker 243213-00 battery
Black and Decker 243215battery
Black and Decker Grasshog CST2000 batterty
Black and Decker Sweeper CS100 battery
Chamberlain 4228 battery
Chamberlain 41A6357-1 EverCharge Standby Power System battery
Chamberlain WD962KD Premium Whisper Drive Plus Garage Access System with EverCharge Standby Power System (Garage Door Opener / System)
Disclaimer: The products supplied by our Company are [replacement for] sold for use with certain products manufacturers, and any reference to products or trademarks of such companies is purely for the purpose of identifying the computers with which our products [are replacement for] may be used. Our Company and this Web site are neither affiliated with, authorized by, licensed by, distributors for, nor related in any way to these computer manufacturers, nor are the products offered for sale through our web site manufactured by or sold with the authorization of the manufacturers of the computers with which our products [are replacement for] may be used.
