6V 9Ah Sealed Lead Acid battery
TLA690S
6V 9Ah SLA ( sealed lead acid ) battery supply by UNICELL in Singapore
UNICELL a Leading battery supplier in Singapore Malaysia Indonesia Philippines and Thailand since 1986 , we carry more the 66,000 model
Order code : TLA690S ( 6V 9.0Ah battery )
Categories: 6V 9 Ah Sealed Lead Acid (SLA) maintenance free battery,
Description: 6V rechargeable battery
Size in mm: Length 98.5 mm x Width 56 mm x Height 118 mm (118 with terminal) + 2mm
Weight: 1.7 Kg
Terminal: F1 (4.7mm or 0.187 inch) type
Application: UPS, Exit light , back-up system
Specifications
• Cells Per Unit: 3
• Voltage Per Unit: 6 V
• Capacity: 9.0 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F)
• Weight (kg): Approx. 1.36kg
• Maximum Discharge current (A): 90A (5sec.)
• Internal Resistance Approx.: Approx. 14mΩ
• Operating Temperature Range:
- Discharge：-15~50(5°F~122°F)
- Charge：-15~40(5°F~104°F)
- Storage：-15~40(5°F~104°F)
• Nominal Operating Temperature Range: 25°C ± 3°C (77°F ± 5°F)
• Float charging voltage: 6.8 to 6.9 VDC/unit Average at 25°C (77°F)
• Recommended Maximum Charging current limit: 2.3A
• Equalization and Cycle Service: 7.2 to 7.5 VDC/unit Average at 25°C (77°F)
• Self Discharge: Batteries can be stored for more than 6 months at 25°C (77°F)
Please charge batteries before using. For higher temperatures the time interval will be shorter.
• Terminal: F1 Faston Tab/ .187"
• Container Material: ABS(UL94-HB/File E50263)*Flammability resistance of(UL94-V0/File E88637) can be available upon request.
Fit or replace battery part no. (Cross refer or compatible chart )
Access SLA665 battery
Access SLA682F battery
Ademco 465680 battery
AJC C8S 6V8AH/20HR battery
Amstron 6V 8Ah battery
Amstron AP-682F1 battery
At-Lite 24-1010 battery
Atlite 341010 battery
BB 6V 9Ah battery
BB BP8-6V battery
BB BP8-6 battery
Chloride 100-001-073 battery
Chloride 100-001-135 battery
CSB 6V 9Ah battery
CSB GP665 battery
Cyclon 26-120 battery
Cyclon 6V 8Ah battery
Cyclon LS080M6 battery
Cyclon 0859-0012 battery
Cyclon 100-001-162 battery
Cyclon 465680 battery
Cyclon 12-707 battery
Cyclon 12-862 battery
Cyclon Kaufel 002008 battery
Cyclon LS040J1 battery
Douglas Guardian DG682 battery
Douglas Guardian DBG6-8F battery
Douglas Guardian DBG682 battery
Douglas Guardian DG6-8F battery
Douglas Guardian DBG68.2 battery
Douglas Guardian DG68.2 battery
Dual Lite 12-535 battery
Dual Lite 12-707 battery
Exide 6GC025J battery
Exide 6GC025K battery
Firstpower FP680 battery
GS Storage PE6V8F1 battery
IBT BT8.5-6 battery
Interstate SLA0945 battery
Interstate 6V 8Ah battery
Interstate BSL0945 battery
Interstate BSL0946 battery
Interstate SLA0043 battery
Interstate SLA0946 battery
Interstate SLA0960 battery
Interstate ABSL0946 battery
Interstate BSL1085 battery
Interstate SLA0935 battery
Kung Long WP9-6A battery
Kung Long WP7-6A battery
Light Alarms CE1-5AL battery
MK ES8.2-6S battery
MK ES8-6 battery
National Power GSA26RMP battery
National Power GSA26R3 battery
National Power GS018Q1 battery
National Power GS018Q3 battery
National Power GS026R3 battery
National Power GS260R3W1 battery
Power Patrol SLA1270 battery
Power-Sonic 6V 8Ah battery
Power-Sonic PS-682 battery
Power-Sonic 6V 8Ah battery
Rhino SLA9-6 battery
Ritar RT680H battery
Ritar 6V 8Ah battery
Siemens Gamma Camera Lem (2 Batteries each)
Sonnenschein 45098900 battery
Sure-Lites 26-04 battery
Sure-Lites 26-01 battery
Sure-Lites 26-03 battery
Tempest TR8-6A battery
Universal UB685 battery
Vision CP680S battery
Fit or replace product model: (Cross refer or compatible chart )
ADI / Ademco 465680 battery
AGT Battery DL12707 battery
Battery Center 0859-0012 battery
Briggs & Stratton LM6 battery
Chloride 1000010162 battery
Cooper Industries KME4215 battery
Dantona 0859-0012 battery
Dual Lite 0120707 battery
Dual Lite 0120749 battery
Dual Lite 12-707 battery
Dual Lite 12-7072P battery
Dual Lite 12-749 battery
Dual Lite 12-752 battery
Dual Lite 12-809 battery
Dual Lite 12-862 battery
Dual Lite 80159 battery
Dual Lite BAT-0340 battery
Dual Lite E4 battery
Dyna Ray S18180 battery
ELS EDS680M battery
Emergi-Lite 6E11 battery
Emergi-Lite 80-159 battery
Emergi-Lite E-11 battery
Enersys 0859 0012 battery
Enersys 0859 1011 battery
Enersys 6E11 battery
Enersys 80159 battery
Enersys 8075J battery
Forma Scientific 8400 battery
Forma Scientific 8407 battery
Forma Scientific 8416 battery
Forma Scientific 8500 battery
Forma Scientific 8516 battery
IDC 08591008 battery
IDC WEED EATER battery
Interstate Batteries ASLA1270 battery
Kaufel 002051 battery
Kaufel 2051 battery
Kaufel 880.0050 battery
Light Alarms V5 battery
McGraw Edison 4X0859-0012W battery
McGraw Edison I04B25708 battery
McGraw Edison KME4-215 battery
Panasonic 08590012 battery
R&d Batteries 5882 battery
Sun Battery 8590012 battery
Trio Lighting TL930088 battery
Unipower B01056 battery
Universal Power Group C6284 battery
Yz Systems 7200GE battery
A3 VITAL SIGNS MONITOR battery
LS040J1 battery
LS080M6 battery
M3926A PORTABLE MONITOR battery
M3927A PORTABLE MONITOR battery
M3928 battery
M3929A PORTABLE MONITOR battery
NPB4000 battery
SLA85912G battery
Unicell International is not affiliated in any way with any of the manufacturers listed in this catalogue and the batteries sold in this catalogue have not been sponsored or approved by any of such manufacturers. Any trademarks or model numbers listed in this catalogue are identified for compatibility or cross-reference purposes only
