12V 120Ah Sealed Lead Acid battery
TLA121200-CP
12V 120Ah sealed lead acid SLA battery supply by UNICELL in Singapore
UNICELL a Leading Supplier for sealed lead acid battery In Singapore Malaysia and Indonesia since1986
Order code : TLA121200-CP ( 12V 120Ah replace the 110Ah old series battery )
Categories: 12V 120Ah Sealed Lead Acid (SLA) maintenance free battery,
Description: 12V rechargeable battery
Size: Length 407 x Width 175 x Height 225 mm (225 mm with terminal) + 5mm
Weight: 38 Kg apx.
Terminal: F5 ( M8 screw )
Application: UPS, Exit light , back-up system
Specifications
- Cells Per Unit: 6
- Voltage Per Unit: 12 V
- Capacity: 120.0Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F)
- Weight (kg): Approx. 38 kg
- Maximum Discharge current (A): 1000 A (5sec.)
- Internal Resistance Approx.: Approx. 4mΩ
- Operating Temperature Range:
- Discharge：-15℃~50℃(5°F~122°F)
- Charge：-15℃~40℃(5°F~104°F)
- Storage：-15℃~40℃(5°F~104°F) - Nominal Operating Temperature Range: 25°C ± 3°C (77°F ± 5°F)
- Float charging voltage: 13.5 to 13.8 VDC/unit Average at 25°C (77°F)
- Recommended Maximum Charging current limit: 36 A
- Equalization and Cycle Service: 14.4 to 15.0 VDC/unit Average at 25°C (77°F)
- Self Discharge: Unicell batteries can be stored for more than 6 months at 25°C (77°F)
Please charge batteries before using. For higher temperatures the time interval will be shorter. - Container Material: ABS(UL94-HB/File E50263)*Flammability resistance of(UL94-V0/File E88637) can be available upon request.
Fit or replace battery part no. (Cross refer or compatible chart )
BB BP120-12 battery
BB BP120.12 battery
B.B. BP120-12 battery
B&B BP120-12 battery
Charirman AGM-12105T battery
CT Leader CT120-12 battery
DM Diamec DM12-100 battery
Firstpower LFP12100S battery
Firstpower LFP1200A battery
Firstpower LFP12120C battery
ICAL LIP12120 battery
IE Industrial Energy IEL 12120 battery
Interstate SLA2624 battery
Haze HZB12-120 battery
Leoch LP12-120 battery
MICROLYTE Plus SEC 12-120 battery
Marathon MIT 120 battery
Marathon MIT 100 battery
Marathon MIT 80 battery
Neata NT12-120 battery
Panasonic LC-R12V120P battery
Power-Sonic PG-12V120FR battery
Power-Sonic PG-12V120FR battery
Ritar RA12-120D battery
Ritar RA12-120 battery
Ritar RA12-120 battery
Vision 6FM120 battery
SEC Microlyte plus SEC 12-120 battery
Sonnenschein A412/100 F10 battery
Sonnenschein A512/120A battery
Sonnenschein A412/100A battery
Sunnyway SW121200 battery
Rocket ES 120-12 battery
Rocket ESC 120-12 battery
Tempest TR120-12B battery
Vision 6FM120 battery
Unicell International is not affiliated in any way with any of the tool manufacturers listed in this catalogue and the batteries sold in this catalogue have not been sponsored or approved by any of such manufacturers. Any trademarks or model numbers listed in this catalogue are identified for compatibility or cross-reference purposes only
